What kinds of pneumatic diaphragm control valve
Time:2020-04-02    Click:497

Zxp pneumatic diaphragm straight through single seat control valve
Zxp new series pneumatic diaphragm straight through single seat control valve adopts top guide structure and is equipped with multi spring actuator. It has the advantages of compact structure, light weight, sensitive action, s-streamline fluid channel, small pressure drop loss, large valve capacity, accurate flow characteristics and convenient disassembly.

ZMAN (P) (m) pneumatic diaphragm control valve
ZMAN (P) (m) pneumatic diaphragm control valve is a kind of widely used pneumatic actuator. It adopts balanced spool structure, with small axial unbalanced force, good stability, and the valve stem is not suitable for vibration. It allows large differential pressure, low noise, large flow capacity and strong adaptability, which makes it suitable for occasions with large flow, large differential pressure and low leakage
Zjhp, zjhm fine small pneumatic diaphragm through single seat, sleeve control valve
This series of products are standard type, adjustment cut-off type, bellows sealing type, jacket insulation type and other varieties. The nominal pressure rating of the products are PN16, 40 and 64; The nominal diameter range is dn20-300. Suitable for liquid temperature from - 200 ℃ to + 560 ℃. The leakage standard is grade IV or grade VI, and the flow characteristic is linear or equal percentage.
Zmabp and zmabn pneumatic diaphragm straight through double seat control valve
This series of products are standard type, bellows sealing type, jacket insulation type and other varieties. The nominal pressure rating of the products are PN16, 40 and 64; The diameter range of valve body is dn25-400. The applicable fluid temperature ranges from - 250 ℃ to + 560 ℃. The leakage standard is grade III and grade IV. The flow characteristics are linear or percentage. A variety of varieties
Zjhq and zjhx pneumatic diaphragm three way combined flow and split flow control valves
There are two kinds of products in this series: three-way confluence and three-way shunt. The nominal pressures are PN16, PN40 and pn64; The nominal diameter range is dn25-300. Applicable fluid temperature from - 60 ℃ to + 450 ℃. The leakage standard is grade IV. There are two kinds of flow characteristics: straight line and parabola.
ZXs new series pneumatic diaphragm angle single seat control valve
ZXs new series pneumatic diaphragm angle single seat control valve adopts top guide structure and multi spring actuator. It has the advantages of compact structure, light weight, sensitive action, large valve capacity, s-streamline fluid channel, small pressure drop loss, large valve capacity, accurate flow characteristics and convenient disassembly.
Zxx (q) pneumatic thin film three way high temperature control valve
Zxx (q) pneumatic thin film three-way high temperature control valve adopts the structure of thin-wall window shaped spool, which is different from the bushing guide of plunger shaped spool. Equipped with multi spring actuator, it has the advantages of compact structure, light weight, small volume and convenient disassembly.
Zxn pneumatic diaphragm straight through double seat control valve
Zxn new series pneumatic diaphragm double seat control valve adopts double guide structure and multi spring actuator. It has the advantages of compact structure, light weight, sensitive action, large valve capacity, accurate flow characteristics and convenient disassembly.
Zxm pneumatic diaphragm through sleeve control valve
Zxm new series pneumatic diaphragm sleeve control valve is a kind of pressure balance control valve. Equipped with multi spring actuator, the overall mechanism is compact, light weight and good stability. The fluid channel is s-streamline, with small pressure drop loss, large allowable pressure difference, low noise and large flow capacity.
